General Description
PVD Series PVDF Pleated Filter Cartridges are made with hydrophilic PVDF membrane
which is with low albumen absorption and excellent chemical compatibility. Double layer
membrane structure guarantees bacteria removal efficiency. This cartridge is widely used
in the seperation and purification process in Pharmaceutical industry.
APPLICATIONS
• Sterile APIs
• EyeDrops, lyophilized powder
• Vaccine,serum and biological products
Specifications
| Removal ratings | 0.22um |
| Media | Hydrophilic PVDF |
| Support | PP |
| Cage / Core / End cap | PP |
| O-Ring | Silicone , EPDM |
| Max. Operating temperature | 80ºC |
| Max. Operating DP | 4.0bar@25ºC 1.5bar@80ºC |
Order Information
For example:
PAA0.22R10S
Rating:0.22um, 222/fin/SS,Length: 10",seal material:Silicone
