![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/e4cd06574d82f29d002becfed4d49c6b.jpg)
Dolce Gusto Coffee Capsule Filling sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine
CPL-2501D
Main features> Two sealing stations.
> Small size, simple, easy to learn and start up.
> Machine framework use SS304, with plexi glass doors and automatic stop when door open (protect operator).
> High accurate motor driven by servo motor.
> PLC controller and real-time monitoring.
> Upgrade type Nitrogen system: flush capsule when outside sealing(Remained Oxygen Level as low as 5%)
> No cup no filling and no sealing (continues production no pause)
Applicable Range
Extended to be able to do two times roll cut and seal, Suitable to fit for ground coffee, powders, herbal tea.Typical for: Nespresso with bottom filter paper, Lavazza Point with bottom filter and Dolce Gusto espresso coffee with inner filter film.
Standard functions and optionals> Auto load empty capsule and sensor check.
> Bottom filter film seal(for Nespresso and Lavazza capsules)
> Filling material(±0.1g)
> Hopper material reloaded by vacuum conveyor lifter.
> Auto clean the cup edge.
> Inner film seal and cover the coffee
> Grab foil lid and place ready on cup.
> Check lid in position and seal (flat seal or ring curve seal)
> Finished capsule grab out.
> Automatic count production quantity.
> Automatic alarm to remind operator
Optional:> UV lamp sterilize
> High precise liquid flavoring pump
> Auger conveyor lifter (replace the vacuum conveyor)
> Finished capsule checker weigher and reject unqualified
> Internet port connection, remote control and online upgrade.
![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/405ff74b08ab28348cba127a49bbe4c8.jpg)
Model | CPL-2501D roll film | CPL-2501D precut film |
Suitable Product | coffee, powders,herbal tea,etc. | |
Suitable sealing | Precut foil suggested(film roll also available) | |
Capacity speed/hour | 25-30 cups/minute | |
Filling weight range | 0-20g*n (set by customer) | |
Accuracy | ±0.05~0.15g | |
Voltage | AC220V/380V 50/60hz need confirm by customer | |
InstalledDimension (LxWxH) | 2035X1250X2200(mm) | |
Weight | 600kg | |
Gross Weight | 640kg |
Detailed Images
Want to see more, visit our video website: expakpacking.en.made-in-china.com
Certifications
![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/c093b84a0ef67728668a75cd9d487e95.jpg)
Company Information
![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/c5e736843cd19e7a030b13a228e811c8.jpg)
![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/633cab3b09a6f773a9bbb010576140d9.jpg)
![Dolce Gusto Coffee Capsule Filling Sealing Machine/Coffee Capsule Packing Machine/Lavazza Capsule Coffee Machine](https://img3.grofrom.com/filterqdsupply/8b30037c664f6677f162a63831cdf92e.jpg)
